DC-DC Converter: 48V to 12V, 100A-DC-DC 컨버터-Shenzhen Bwitt Co., 유한회사

Description

20 years of industry experience

Are mainly used in the telecommunication service center,
Railway Control Center ，internet/data exchange center,
industrial automation, automated office, DC screen/cabinet, etc.
To meet your various needs.

문의

Product details

회사 프로필

CON1000 Series DC-DC Converter
1. Specification
Input and output complete isolation, safety and credibility. Reliable circuit topological structure and advance current control mode All-around protection functions, output overlunder voltage, over current, short-circuit and over temperature protection of whole body Can parallel connection, convenient to extend the capacity, adopt no-master automatic equalized current technology AC and DC input are available

Table 1: Model List
Model	5A	10A	20A	40A	50A
Support parallel
DC Input
20-30Vdc	√	√	×	√	√
40-50Vdc	×	√	√	√	√
90-140Vdc	×	√	√	√	√
180-270Vdc	×	√	√	√	√
DC Output
20-30Vdc	×	×	×	√	√
40-50Vdc	×	×	×	√	×
90-140Vdc	×	√	√	×	×
180-270Vdc	√	√	×	×	×
General Parameters
Load regulation	≤0.2%
Power grid regulation	≤0.1%
Degree of imbalance for equalized current	≤±5%
Phone weighted noise voltage	≤2mV（CCITT）
Peak—peak noise	≤150mV
Wide frequency noise	≤50mV
Discrete noise	≤20mV
Efficiency	≧83%
Dynamic response	20% ~ 100% step load≤200Restoring time≤100us
Working temperature	-10℃~50℃
Cooling mode	Temperature control wind cooling
MTBF	100,000Hour
Weight	8kg
Dimension	48224088mm
